ZD series
Beijing Origin Water Co., Ltd
Features:
ZD series membrane products of Beijing Origin Water Co., Ltd are designed for and can be applied in every stage of waste water zero discharge membrane process. Based on different industies' waste water features and requirements of the treatment process, ZD series membrance product select appropriate process design and membrane elements to improve the waste water recovery rate. With the ZD series membrane products, the concentrated water after being processed enters into state of evaporated crystallization, enabling the entire process to achieve the object of zero discharge of waste water, and effectively reduce the plant construction cost and operation cost.
The products have been sucessfully installed and operated in a Natural Gas Project in Xinjiang, China.(Designed Capacity: 5.5 billion m3/year)
Specifications:
| Type | Max. Operation Pressure | AV. Desalination Rate | Min. Desalination Rate | Product Feature |
| FLM-ZD-FR | 4.1Mpa | 99.7% | 99.5% | Zero discharge preliminary concentration; lower differential pressure; higly fouling resistance coating; |
| FLM-ZD-HP7 | 8Mpa | 99.75% | 99.6% | Zero discharge secondary concentration; higly chemical duration;anti-fouling coating; |
| FLM-ZD-N | 4.1Mpa | 98% | 97% | Separating monovalent and divalent salt from the concentrated water; |
| FLM-ZD-NHP | 8Mpa | 99% | 97% | Treating water before going into hyperosmosis process, to separate monovalent and divalent salt |
